  • Merry Christmas from Airclean December 5, 2017

    Merry Christmas and a Happy New Year

    Airclean will close at 5pm on Thursday 21st December 2017 and will reopen on Wednesday 3rd January 2018.

    Where you have deliveries that you require before the Christmas break please get them into us as soon as possible and speak to the sales team if you have any specific requirements.

    Don’t forget those early January orders, we are already programming our schedules for our first weeks back!

    Finally we would like to say a big thank you to all of our customers and suppliers who we have worked with this year.

    Any problems, or if you need items by a certain date, please contact us.
    Tel: 01622 832777, email: sales@airclean.co.uk
    .

  • How to measure your canopy Mesh Grease Filters October 4, 2017

    Mesh Grease Filter Measuring Guide

    1. Use a good tape measure
    2. Measure all three dimensions in mm (millimetres)
    3. Write down the sizes
    4. Measure all of your mesh grease filters – you never know, one might be a different size
    5. Don’t forget to count how many filters you need.
    6. Give us a call for our best prices –   01622 832777

    (If you struggle with mm, and would prefer to measure in inches this is fine too.)

    measuring kitchen mesh grease filters

    Standard Kitchen Mesh Type Grease Filters

    The following mesh grease filters are our standard sizes.  We generally keep these sizes in stock for quick delivery.

    If you can’t find your size on the list below then give us a call, you probably need custom mesh grease filters made specially for you!

    Our Standard Mesh Grease Filters are made from galvanised steel and come with handles and drain holes.  Our quality mesh grease filters are long lasting and robust.

    kitchen canopy mesh grease filters
    SizeAirflow (m3/s)P.D. (Pa)Price
    ex. VAT
    Part Number
    OT InchesActual (mm)
    10 x 10 x 2242 x 242 x 470.1530£24.521310201
    12 x 12 x 2292 x 292 x 470.2130£27.731310202
    15 x 15 x 2369 x 369 x 470.3430£33.381310203
    16 x 16 x 2394 x 394 x 470.3930£33.381310204
    18 x 9 x 2445 x 216 x 470.2430£33.381310205
    18 x 18 x 2445 x 445 x 470.530£36.281310206
    20 x 10 x 2495 x 242 x 470.330£30.141310207
    20 x 16 x 2495 x 394 x 470.4930£36.281310208
    20 x 20 x 2495 x 495 x 470.6130£41.761310209
    25 x 16 x 2623 x 394 x 470.6130£45.301310210
    25 x 20 x 2623 x 495 x 470.7730£46.591310211
    24 x 24 x 2597 x 597 x 470.8930£49.961310212
    SizeAirflow (m3/s)P.D. (Pa)Price
    ex. VAT
    Part Number
    OT InchesActual (mm)
    10 x 10 x 1242 x 242 x 220.1525£21.611310101
    12 x 12 x 1292 x 292 x 220.2125£22.881310102
    15 x 15 x 1369 x 369 x 220.3425£26.761310103
    16 x 16 x 1394 x 394 x 220.3925£26.761310104
    18 x 9 x 1445 x 216 x 220.2425£26.761310105
    18 x 18 x 1445 x 445 x 220.525£30.321310106
    20 x 10 x 1495 x 242 x 220.325£24.201310107
    20 x 16 x 1495 x 394 x 220.4925£30.321310108
    20 x 20 x 1495 x 495 x 220.6125£34.841310109
    25 x 16 x 1623 x 394 x 220.6125£38.681310110
    25 x 20 x 1623 x 495 x 220.7725£40.291310111
    24 x 24 x 1597 x 597 x 220.8925£45.441310112

    Want to order?  Can’t find your size – Give our helpful team a call! 01622 832777

  • How to measure your kitchen canopy Baffle Grease Filters October 4, 2017

    Baffle Grease Filter Measuring Guide

    1. Use a good tape measure
    2. Measure all three dimensions in mm (millimetres)
    3. Write down the sizes
    4. Measure all of your baffle grease filters – you never know, one might be a different size
    5. Don’t forget to count how many filters you need.
    6. Give us a call for our best prices –   01622 832777

    (If you struggle with mm, and would prefer to measure in inches this is fine too.)

    measuring baffle kitchen canopy grease filters

    Standard Kitchen Baffle Grease Filters

    The following baffle grease filters are our standard sizes.  We generally keep these sizes in stock for quick delivery.

    If you can’t find your size on the list below then give us a call, you probably need custom baffle grease filters made specially for you!

    Our Standard Baffle Grease Filters are made from a polished finish Stainless Steel, and are long lasting and robust.

    baffle grease filters
    SizeAirflow (m3/s)P.D. (Pa)Price
    ex. VAT
    Part Number
    OT InchesActual (mm)
    16 x 16 x 2394 x 394 x 470.25125£60.341321119
    20 x 10 x 2495 x 242 x 470.19125£60.341321120
    20 x 16 x 2495 x 394 x 470.31125£63.601321121
    20 x 20 x 2495 x 495 x 470.39125£73.481321122
    18 x 18 x 2445 x 445 x 470.31125£70.671321123
    24 x 24 x 2594 x 594 x 470.54125£96.101321124

    Want to order?  Can’t find your size – Give our helpful team a call! 01622 832777

  • How to use the Airclean’s IAQFS to filter NOx / NO2 in your school or office September 18, 2017

    Our new technical bulletin aims explain how Airclean’s Indoor Air Quality Filtration System can be used in conjunction with a fan, to filter and mitigate Nitrogen Dioxide (NOx / NO2), particulate matter (PM10, PM2.5), VOCs and other airbourne pollutants.

    These pollution mitigation methods are beoming more common to protect occupants in buildings which are located in areas where pollution levels such as nitrogen dioxide are exceeding the limits set by local authorities and the EU in public and private buildings such as schools, offices and domestic properties.

    NOx Filter for indoor air pollution filtration solutions

    Click below to download :

    Technical Bulletin – Indoor Air Quality Filtration System and Nox NO2 Mitigation

    If you wish to discuss your building and how you can filter nitrogen dioxide (NOx, NO2) in your home, office or school give us a call on 01622 832777

  • ISO 16890 – The New Standard in Air Filtration Replacing EN779 August 29, 2017

    The ISO 16890 Test Standard was introduced in late 2016 and is currently in an 18 month transition period where the current EU test standard for air filters, EN779:2012 will be replaced.

    The EN779 test standard centered itself around an air filter’s ability to capture a single size particle which was 0.4µm.  The new ISO 16890 attempts to provide a test more sympathetic to real operating conditions by testing against a range of particle sizes from 0.3µm through to 10 µm.

    Testing to ISO 16890 will catagorise air filters into four initial categories.

    ePM2.5 Air Filters for removing Pollen particles
    This image shows pollen particles which range in size up to 2.5 microns, (PM2.5). Filters of ePM2.5 can be selected as the minimum requirement to remove such particulates.
    ISO 16890 GroupsISO 16890 Efficiencies
    Coarse< 50% of PM10
    ePM10≥ 50% of PM10
    ePM2.5≥ 50% of PM2.5
    ePM1≥ 50% of PM1

    Within these four categories each available air filter will have to state their efficiencies against the individual particle sizes – PM1, PM2.5 and PM10.

    The following table offers guidance on how these catagories are likely to look, and how they sit next to EN779:2012.

    ClassISO ePM1ISO ePM2.5ISO ePM10ISO Coarse
    G3--->80%
    G4--->90%
    M5-->50%-
    M6-50 – 65%>60%-
    F750 – 65%65 – 80%>85%-
    F865 – 80%>80%>90%-
    F9>80%>95%>95%-

    This new testing standard aligns with the current adoption of the Particulate Matter sizing in relation to Human Health.  We believe this step forward will in turn will assist in the understanding and specifying of air filters for their desired application.

    As this standard rolls out and settles in the market, you will see Airclean products adopt and confirm where they sit against the new ISO 16890.

    If you require further assistance sooner, please contact us and our technical sales team for advice.
